دتکتور شعله اسپکترکس (IR (IR3 مدل 20/20MI-11-S-C
Spectrex IR (IR3) Flame Detector 20/20MI-11-S-C
|
Model
(مدل) |
20/20MI | ||
|
Part Number
(شماره قطعه) |
20/20MI-11-S-C | ||
|
Sensor Type
(نوع سنسور) |
IR3 | ||
|
Spectral Response
(طیف پاسخ دهی) |
Three IR Bands | ||
|
Detection Range
(بازه سنجش) |
Alcohol (Ethanol) 100/30, Diesel Fuel90/27, Gasoline133/40, IPA (Isopropyl Alcohol) 100/30, JP5 100/30, Kerosene 100/30, LPG (Propane) 40/12, Methane 40/12, Methanol 100/30, n-Heptane133/40, Officer Paper 50/15, Polypropylene Pellets 16/5 | ||
|
Response Time
(زمان پاسخ دهی) |
Typically 5 seconds | ||
|
Sensitivity Ranges
(بازه حساسیت) |
33 ft (10m) to 133 ft (40m) | ||
|
Field of View
(زاویه دید) |
100° horizontal\, 100° vertical | ||
|
Built-in-Test (BIT)
(تست داخلی) |
Manual and Automatic BIT | ||
|
Operating Voltage
(ولتاژ عملکرد) |
18-32V DC | ||
|
Power Consumption
(توان مصرفی) |
Max. 25 mA in stand-by, Max. 50 mA in alarm | ||
|
Output
(خروجی) |
Relays | ||
|
Communication
(نوع ارتباط) |
Modbus, RS485 | ||
|
Operating Temperature
(دمای قابل تحمل) |
Operating: -40°F (-40°C) to 160°F (70°C), Storage: -65°F (-55°C) to 185°F (85°C) | ||
|
Ingress Protection
(حفاظت داخلی) |
IP66 and IP67 per EN60529, NEMA 250 6P | ||
|
Operating Humidity
(رطوبت قابل تحمل) |
Up to 95% | ||
|
Entries
(ورودی) |
12 wires 6 ft. (2m) cable (for junction box connection) | ||
|
Housing Material
(جنس بدنه) |
Stainless Steel 316L with electro polish finish | ||
|
Certifications
(گواهینامه‌ها) |
ATEX and IECEx : Ex II 2 G D Ex db eb op is IIC T4 Gb Ex tb op is IIIC T96°C Db (-55°C Ta +75°C) Ex db eb op is IIC T4 Gb Ex tb op is IIIC T106°C Db (-55°C Ta +85°C) | ||
|
Manufacture
(سازنده) |
Spectrex | ||
|
Manufacture
(سازنده) |
Spectrex |
